CNC Vertical type V grooving machine

Product description

This equipment is fully CNC V Groover Machine for metal sheet. It adopts advanced CNC system and innovative design with the advantages of high processing precision, simple operation, no noise, no vibration and so on. It is widely used in the sheet metal V-groove, U-groove and other irregular groove processing (including stainless steel, aluminum, aluminum plate, copper, iron, plastic, wood, acrylic panels and other special plates).Particularly.It is applicable to the V-groove processing of sheet metal before bending .


Structural Features

Whole machine body welded by steel plates with high strength and small deformation.

Full CNC automatic working.

Automatic clamping and loosening.

Blade moving meanwhile sheet works stay in its place,so save space.

Quick changing of blades.

Three sets blades working together to save time.

Knock-down front support arms for long work pieces.

Servo motor to ensure high precision.

Less noise and high performance.


Item HK model
grooving material width 1250mm 1250mm 1250mm
grooving material width 4000mm 5000mm 6000mm
grooving material thickness 0.40-4.00mm 0.40-4.00mm 0.40-4.00mm
distance between sheet edge to the V edge 8mm 8mm 8mm
x axis moving speed 70m/min 70m/min 70m/min
x axis return speed 85m/min 85m/min 85m/min
Y axis moving speed 20m/min 20m/min 20m/min
Y/Z axis position accuracy ±0.01mm ±0.01mm ±0.01mm
x axis motor power 4.5KW 4.5KW 4.5KW
Y/Z axis motor power 1KW 1KW 1KW
machine overall size 5740x2350x2110mm 6740x2350x2110mm 7740x2350x2110mm
weight 13T 15T 20T
